1 Introduction

As a 21st century green engineering metal structure material, magnesium alloy is characterized by low density, high specific strength and stiffness, good damping performance, convenient machining and easy recycling [1–4]. These advantages make it widely used in automotive, 3C aerospace and other fields [5–7]. However, magnesium and magnesium alloys are HCP structure [8], when the deformation temperature is below 225 °C, plastic deformation is limited to the basal plane {0001}<11 2 0> slip and pyramidal plane {10 1 2}<10 1 1> twinning [9–12]. Figure 1 gives HCP structure of magnesium alloys. Its plasticity at room temperature is very low, which severely limits the magnesium and magnesium alloy applications [13].

To realize the value of magnesium and magnesium alloys, we must firstly solve the plastic problem. From the Hall-Petch formula (1) it can be known that grain refinement can improve the strength and ductility of the material:(1)

where σs is yield strength, σ0 is the yield limit of monocrystal, k is a constant and d is the grain size. Under normal circumstances, the material slip system number determines the value of Taylor coefficient. There is a positive relationship between the value of k and Taylor coefficients. magnesium and magnesium alloys Taylor coefficient are larger due to the hcp structure relative to the face-centered cubic and body centered cubic, so its k is larger, and the potential through grain refinement method to improve the magnesium alloy plastic of is much greater than the iron alloy, aluminum alloy, etc. [14–16]. The main reason why finer-grained materials are stronger and harder than coarser-grained materials are that fine materials have a relatively large grain boundary area [17,18].

Equal channel angular processing is developed by Segal and is one of the most effective methods to improve one of the plastics materials currently [19–21]. Many studies have proved the equal channel angular extrusion can significantly refine the material grain. Aiming at the research on the deformation mechanism of equal channel angular extrusion, Xu et al. [22] studied the deformation uniformity of multi-pass ECAE process by using finite element analysis. He et al. [23]. found that isometric angle extrusion was performed on Fe-0.8C all-pearlitic steel at 923 K. After one isometric angle extrusion, the carburized lamellae were bent, kinked and fractured, and their spacing was significantly reduced. After four passes, the grain size was submicron ultra-fine biphasic (ferrite + carburite) and transformed the planar lamellae into equiaxed three-dimensional grains. Dynamic and continuous recrystallization occurs during the isometric angular extrusion deformation, forming isometric ferrite grains with an average size of 400 nm. Jiang and Da [24] extruded two kinds of Al-Mg-Mn alloy having similar composition but with and without Zr addition at 350 °C and the crystal grains of 1-2 µm were obtained after six times. Figure 2 shows schematic diagram of an ECAP die. Two channels of equal cross-sectional area intersected at a certain angle. One angle is died angle Φ, another is dying corner angle Ψ. In Equal channel angular pressing process, the billet moves downward the punch pressure P. when it is through the die corner, the billet will produce the nearly ideal shear deformation. Since the deformation process does not change the cross-sectional shape and area of the material, so the total strain can be accumulated from repeated extrusion. Under ideal conditions, the size of the shear strain after one pass by the formula (2) [25–28] determined by:(2)

In addition, the total equivalent strain after N passes can be represented by the formula (3):(3)

Only if one assumption is met which is no friction, the formula (3) is only established [29,30]. Some researchers [31,32] have been verified the formula (3) through experimental study and have proved its rationality. Through finite element simulation, it is found that the dead zone is easily generated when Φ = 90° and Ψ = 0°, while it can be minimized when Φ = 90° and Ψ = 20° [33–35].

When Ψ = 0, Φ = 2 ϕ, the above formula can be described as:(4)

This formula is consistent with the equivalent strain accumulation formula derived by Segal earlier using the slip line method [36].

In this paper, dynamic simulation of AZ31 magnesium alloy equal channel angular processing was carried out through finite element software Deform-2D, which simulated the deformation under different process parameters and analyzed the changes of field quantities during the deformation of magnesium alloy AZ31 ECAP.

thumbnail Fig. 1

HCP structure of magnesium alloy.
thumbnail Fig. 2

Schematic diagram of an ECAP die.

2 Finite element model

The finite element software Deform-2D software is a set of process simulation system based on finite element for the analysis of metal forming and related industry forming process and heat treatment processes. During the simulation, the billet is magnesium alloy square billet AZ31 of size 12 × 12 × 60 mm. Deform software material library has no the specific parameters of AZ31 magnesium alloy, so it is needed to determine the flow stress of AZ31 magnesium alloy relations, that is equation (5):(5)

Where c and y are constants, c = 205, y = 0. The strain index n = 0.044, the strain rate exponent m = 0.144. During equal channel angular processing, the geometry of the mold doesn't change, so the die is set to a rigid body during the simulation process, the billet is a deformable body, so it is set as a rigid plastic body. The meshing number is 8000, and the node number is 8241. The die parameters include die channel angle Φ and die corner angle Ψ. Theoretically, die channel angle Φ and die corner angle Ψ are in the range of 0° to 180°, but the actual die corner angle Ψ is preferably in the range of from 0° to 90°, the die channel angle Φ is preferably in the range of 90° to 150°. The specific parameters are shown in Table 1. During the finite element simulation, the size of the die corner angle is mainly determined by the radius of the outer arc of the die. Figure 3 gives the relationship between the die corner angle, the die outer arc radius and the width of the die channel. From Figure 3, the relationship between die corner angle, the die outer arc radius and width of the die channel can be deduced [37,38]:(6)

When die channel angle Φ = 90°,(7)

When die channel angle was 90° and the value of the die corner angle were 15°, 26°, 37° and 52° respectively, the corresponding radius R can be calculated by bringing them into equation (7), and they are 2.79 mm, 4.5 mm, 6 mm, and 7.87 mm, respectively.

In order to analyze the uniformity of the deformation of the workpiece. Figure 4 gives three sections and nodes where the deformation was observed: the upper surface, the middle surface and the lower surface. Thirteen nodes were selected for each section. The field quantities of these sections and nodes were analyzed.

Table 1

The process parameters for the simulations of the square-section channel of ECAP process.

thumbnail Fig. 3

The relationship between the die corner angle, the die outer arc radius and of the width of the die.
thumbnail Fig. 4

Sections and nodes selected to observe deformation.

3 Results and analysis

3.1 Effect of die channel angle

Table 1 shows each parameter value, the selected value of die channel angles is 90°, 100°, 110° and 120°.The die corner angle is 37° and the inner arc radius r is 2 mm in the same time. Figure 5 shows the effective strain of nodes on three sections of workpiece: (a) Φ = 90°; (b) Φ = 100°; (c) Φ = 110°; (d) Φ = 120°. The horizontal axis of the curve represents distance of each node from the workpiece left side surface and the vertical axis represents the equivalent strain of each node. As can be seen from the figure the workpiece after deformed can be divided into three parts, namely the head deformation zone, the main deformation zone and tail deformation zone, which is consistent with the study of Xu et al. [39]. The head deformation zone: This is the first extrusion part, which is 50–60 mm part in the figure. The deformation of this part is very uneven, equivalent strain distribution gradient is bigger. The main deformation zone: This section takes up about 2/3 of workpiece along the length direction, which is 10–50 mm part. In the horizontal direction, the equivalent strain distribution is uniform. But in the direction of perpendicular to the horizontal direction of workpiece, the deformation is not uniform. The tail deformation zone: that is in the deformation stage, which is in the part of the 0–10 mm. This part deformation is not complete. if realized extrusion continuously of the workpiece, there is no tail deformation, and therefore this part can be negligible. From the figure, it can also be seen that with the increase of the die channel angle, the upper, equivalent strain gap of middle and lower three section gets smaller, that is, the greater the die channel angle, the more uniform deformation of the workpiece.

thumbnail Fig. 5

Effective strain of nodes on three sections of workpiece: (a) Φ = 90°; (b) Φ = 100°; (c) Φ = 110°; (d) Φ = 120°.

3.2 Effect of die corner angle

Figure 6 represents the equivalent strain curves at different nodes of the three cross-sections when the die corner angle are 15°, 26°, 37° and 52°, respectively, and the die channel angle is 90°. From the figure, it can be seen that the die corner angle has little effect on the size of the equivalent strain of the workpiece, and has no significant effect on the deformation geometry and deformation uniformity of the workpiece. But this does not mean that die corner angle does not affect the magnesium alloy ECAP deformation. Figure 7 presents the deformation of the workpiece and the mesh during simulation when the die corner angle are respectively 15°, 26°, 37° and 52° whit the die channel angle of 90°. The four selected die corner angle could not prevent the formation of the dead zone. The dead zone is the gap formed between the workpiece and the die as the workpiece passes through the die corners. The area of the dead zone increases as the angle of the die corner angle increases. Therefore, it is necessary to select smaller die corner angles in order to produce smaller dead zones in the ECAP process. The element of the unsqueezed workpiece is rectangular, and the rectangular element deforms into an elongated shape, as shown at nodes p4, p5, and p6, which are subjected to shear when the workpiece passes through the die corner. When the mold corner angle is different, the tail of the workpiece will appear different degrees of warping phenomenon, that is, p1, p2, p3 can not maintain the level. The larger the die angle, the larger the angle between p1, p2, p3 and the horizontal direction, and the more serious the warpage of the workpiece. When the die channel angles are 37° and 52°, a small gap is also formed between the die and the upper and lower surfaces of the workpiece, which may result in a slight reduction in the longitudinal dimension of the extruded workpiece.

The deformation characteristics of the ECAP process were analyzed and an algorithm for rigid-plastic finite elements was given. The mechanism of the ECAP process for square and round workpieces were analyzed using the commercial metal forming finite element code DEFORM-2D. From the results of the study, the die geometry of ECAP has a large influence on the extrusion process. The strain distribution on the ECAP with different die channel angles is the same, and the derived equation (3) agrees well with the actual simulation results. A range of optimum values for the die channel angle and die corner angle is given, taking into account the effect of deformation intensity and stress on the die. For materials with low resistance to deformation, it is necessary to obtain workpieces with good deformation distribution and high equivalent strain values. When the strength of the die is sufficient, smaller die channel angle and die corner angle can be selected to improve the cumulative deformation effect. When the deformation resistance of the material is high, it is recommended to select larger die channel angles and mold corners. Therefore, the die channel angle and die corner angle of ECAP should be carefully considered in the experiment.

thumbnail Fig. 6

Effective strain of nodes on three sections of workpiece: (a) Ψ = 15°; (b) Ψ = 26°; (c) Ψ = 37°; (d) Ψ = 52°.
thumbnail Fig. 7

The deformation in the cross-section of workpiece for different corner angle at Φ = 90°: (a) corner angle of Ψ = 15°; (b) corner angle of Ψ = 26°; (c) corner angle of Ψ = 37°; (d) corner angle of Ψ = 52°.

4 Conclusions

The effects of the die channel angle and the die corner angle on workpiece deformation uniformity have been researched and analyzed by the two-dimensional finite element simulation of magnesium alloy ECAP process, and the following conclusions are drawn:

  • According to the deformation after extrusion, the workpiece can be divided into three parts: head deformation zone, main deformation zone and tail deformation zone. In the main deformation zone, the die channel angle has little effect on the uniformity of the longitudinal deformation of the workpiece, and the larger the die channel angle is, the more uniform the longitudinal deformation of the workpieces are.

  • The die corner angle has little effect on the uniformity of longitudinal deformation of the workpiece, and when the die corner angles are different, the equivalent deformation in the horizontal direction does not change much.

  • The die corner angles have some influence on the dead zone area and workpiece warpage. The dead zone area and workpiece warpage increase with the increase of die angle. When the mold angle is 37° and 52°, a small gap is formed between the mold and the upper and lower surfaces of the workpiece.
